PC Cover High Bay Light LED 150W 200W 100W
Model Number:
LED Power:
Input Voltage:
CCT:
Luminous：
Certification:
RB-HB-150WU2
150W
100-277V/347-480V AC
3000K-7000K
19500LM
CE/EMC/ETL/ROHS
Product Detail
100W 150W 200W 250W UFO LED High Bay Light PC Cover Anti-glare
ED Industrial Light/UFO High Bay Light Products Features:
Product Description
-
Control method/Dimmable: We adopt high reliable durable driver which can used on a wide range of voltage: 100-240V/100-277V/347- 480V/AC,this driver allows you dim function by connect it with a standard (1-10V) dimmer.Microwave sensor with dimmable,Zigbee Smart control,Bluetooth Smart control.
-
High Quality Chips: 3030/2835 SMD LED high quality chips will provide you with the best illumination experience with output lumen reaches up to 140-170LM/W. It won't consume too much energy so that you can save much electricity cost,what's more, the color temperature is 3000K/4000K/5000K/5700K/6000K/6500K and CRI>80%, it helps to deliver more realistic color for the objects which is much more friendly to human eyes.
-
Efficient Heat Dissipation: The special outer casing hollow design can provide an amazing heat dissipation effect to ensure much longer effective working time of the LED high bay light.
-
Made from a durable aluminum housing,the enhanced thermal management of our LED High Bay Light wicks away heat via the heat sinks convection heat exchange with ambient air.
-
Reflector 60° 90° 120° beam angle is available,meet the requirements of professional light distribution and can be use at different place.
-
IP65 Waterproof: Waterproof design,elimination mist,avoid condensation,suitable for usage in wet environments, no need to worry lamp getting damaged from water or splashes.widely use for indoor and outdoor.
-
Long Power Cable: We can also provide the power plug of the extension cord for customers to install conveniently.
-
LED pendant light LED junction temperature less than 85C.
-
LM79/LM80/IES reports available and simulation.
-
ETL/SAA/CE/RoHS certification.
-
Two installations: Bracket & Hooking Hang for options.
-
Lighter weight and smaller volume can help customer save freight cost.
-
LED metal halide replacement
-
5 years warranty.
|
150W UFO LED HIGH BAY
|
|
Item No.:
|
RB-HB-150WU2-PC
|
|
Input Voltage:
|
AC 100-277V
|
|
Freqency Range:
|
50Hz~60Hz
|
|
LED Chip:
|
Lumileds chip
|
|
Power Factor:
|
>0.98
|
|
Power Efficiency:
|
>92%
|
|
Luminous Efficiency:
|
140LM/W
|
|
LED Power
|
150W
|
|
LED QTY: 216
|
216pcs
|
|
LED Working Voltage:
|
DC 42~48V
|
|
System Consumption:
|
150W
|
|
LIGHT Luminous Flux
|
Warm White
|
19800LM
|
|
Pure White
|
22500LM
|
|
Cool White
|
22600LM
|
|
Viewing Angle:
|
120/90/60 degree
|
|
Center Luminance
|
Height 6M
|
221LUX
|
|
Height 8M
|
113LUX
|
|
Height 10M
|
98LUX
|
|
Illuminance Area
|
Height 6M
|
Dia.1893CM points visible
|
|
Height 8M
|
Dia.2525CM points visible
|
|
Height 10M
|
Dia.3156CM points visible
|
|
Illuminance Uniformity:
|
>0.6
|
|
Color Temperature
|
Warm White
|
3000K~3500K
|
|
Pure White
|
4000K~5500K
|
|
Cool White
|
6000K~6500K
|
|
Color Rendering Index
|
Ra>80
|
|
Light Distribution:
|
LED points visible
|
|
LED Junction Temperature:
|
≤115℃
|
|
Working Temperature:
|
–35℃~65℃
|
|
IP Grade:
|
IP65
|
|
Working Life-span:
|
50000 H
|
|
Power Line:
|
1.0 mm² three line
|
|
Connect Wire
|
Brown
|
L
|
|
Blue
|
N
|
|
Yellow / Green
|
G
|
|
Certificate
|
CE/ETL/SAA/ROHS
|
|
Size:
|
Ø350*H185mm
|
